Repeaters

Please note items in red are under construction or otherwise off the air.

Mount Bullion

Mount Bullion is located a few miles out of Mariposa.  All repeaters and remote bases are controlled by one of the two RLC-DSP404 controllers.  All repeaters and remote bases can be linked to any other analog equipment on Mt. Bullion.

Repeaters:
147.03 MHz + (100Hz)
224.96 – (156.7Hz)
420 Hub
444.7 MHz + (94.8Hz)
1284.3 – (88.6Hz)

Remote Bases:
29.6 MHz FM
52.525 MHz FM

Remote Receivers

These receivers act as cross band repeaters between 147.63 MHz and 449.7 MHz.  All of these receivers are bi-directional meaning you can transmit into them on either 2 Meters or 440 except for Turlock.  Both UHF and VHF PLs are the same for all of the receivers.

Turlock: 103.5 Hz
Los Banos: 107.2 Hz
Atwater: 114.8 Hz
Fresno: 118.8 Hz

Turlock

In the city of Turlock TARC has a VHF repeater, remote receiver, as well as a 2 Meter/440 remote base.  Under normal circumstances the Turlock system is configured as a remote receiver.  When it is configured this way it is only mono-directional, 2 Meters input only.  The Turlock system can also be configured so that the remote base is being repeated through the UHF/VHF repeater on Mount Bullion.  The frequency of the repeater/remote receiver is as follows:

Turlock: 147.03 MHz + (103.5Hz)

Merced

In the city of Merced, TARC has a UHF repeater. Under normal circumstances the Merced Repeater is linked and repeated through the UHF/VHF repeater on Mount Bullion.

The frequency of the Merced repeater is as follows:

Merced: 444.900 MHz + (94.8Hz)

Yosemite

TARC has two repeaters in Yosemite National Park.  Both repeaters are normally linked to the rest of the system via the 420 hub, but if necessary can be unlinked at anytime.  Both repeaters have excellent coverage in and around the park.

Turtleback Dome: 147.000 MHz + (100Hz)
Sentinel Dome: 444.925 MHz + (94.8Hz)

Buck Rock

TARC has a UHF repeater in Sequoia National Forest on Buck Rock near Kings Canyon National Park.  The repeater is normally linked to the rest of the system via the 420 link but can be unlinked at any time.

Buck Rock: 440.30 MHz + (94.8Hz)

DMR

TARC has four DMR repeaters. All four repeaters are tied to the brandmeister network on both timeslots.

The Turlock Amateur Radio Club advises the use of TARC regional instead of local. This allows for better and easier use of the TARC repeaters.

TARC Regional: 310658 (Timeslot 2)

Mount Bullion UHF: TX: 444.7875 – RX: 449.7875 – CC: 1
Mount Bullion VHF: TX: 144.9375 – RX: 147.4375 – CC: 1
Mount Oso: TX: 440.1875 – RX: 445.1875 – CC: 1
Turlock Low Level: TX: 444.350 – RX: 449.350 – CC: 2

All TARC DMR repeaters have the following static talkgroups.

Static Talkgroups:

NorCal: 31068 (Timeslot 1)
California: 3106 (Timeslot 1)
Local: 2 (Timeslot 2)
TARC Regional: 310658 (Timeslot 2)

Except for TARC Regional and local, all traffic should take place on timeslot 1.

Standard Talkgroups:

Although all brandmeister talkgroups will work, TARC members have the following as a minimum:

Local: 2
NorCal: 31068
NorCal 1: 31069
California: 3106
Cal 1: 31061
SoCal: 31066
SoCal 1: 31067
Southwest: 3176
Call Zone 6: 31096
North America: 93
Worldwide: 91
TAC 310: 310
TAC 311: 311
TAC 312: 312

Broad Band Microwave

Amateur Radio Emergency Data Network (AREDN) (MESH Network)

W6BXN is operating a 5 GHz, 90° Sector Microwave Antenna on Mt. Bullion.
Coverage area should be from Turlock along highway 99 down to South of Merced.
SSID: AREDN, Ch.179 (5.895), 10 MHz wide.

W6BXN is operating a 5 GHz 90° Sector Microwave Antenna on Mt. Oso.
Coverage area should be South of Modesto to Turlock along highway 165 down to Los Banos.

SSID: AREDN, Ch.174 (5.870 GHz), 10 MHz Wide

W6BXN is now testing a M5 90° 21db North Sector Antenna on Mt. Oso.
Coverage should be South of Stockton to Turlock, Covering the Hwy 99 corridor.
SSID: AREDN, 5GHz. Ch 164 (5.820) 10 Mhz wide

W6BXN is operating a 5 GHz, Omni Antenna in the city of Turlock
Covering the city of Turlock. Node is located at 6th street C street.
SSID: AREDN, Ch.164 (5.820), 10 MHz wide.

W6BXN is operating a 5 GHz, Sector Antenna in the city of Merced
Covering the city of Merced. Node is located near Merced JC.
SSID: AREDN, Ch.164 (5.820), 10 MHz wide.

www.facebook.com/sjvmesh

www.arednmesh.org
